6×60W LED Pixel Zoom Bar Moving Head Light

1. Equipped with 6×60W RGBW 4 in 1 LEDs and 324pcs 02W RGB 3 in 1 LEDs
2.Zoom range: 3 ° to 40 °
3.XY unlimited rotation
4.Extended functions: support RDM, wireless signals is available

Availability:
Quantity:
  • WOP-LM4004B

  • Wincode Optronics

WOP-LM4004B 6×60W LED Infinite Blade Moving Head Light is powered with 6 pieces 60W RGBW 4 in 1 LEDs for main wash light with zoom and 324pcs 02W RGB 3 in 1 LEDs for back strobe light. A XY unlimited rotation moving head light effect led product, with 3 ° to 40 ° zooming range, forming a "blade" mirror effect cutting space at 3 ° and a wide dyeing range at 40 ° and pure color without color difference; single point control of lamp beads can form rich effects. It’s one impressive dynamic LED Zoom Pixel Moving Bar Light with beam effects, pixel effects, wash effects for night club, DJ Events…



Product parameters

Light Source

Light Source: 6x60W RGBW LED

LED life expectancy: 30,000 hours



Optical System & Effects

Zoom range: 3°—40°

RGBW color mixing

Outstanding color mixing effect with variable speed

High resolution dimmer 0–100%



Electromechanical Effects

Linear motorized zoom

Pan:360°  unlimited

Tilt: 360°  unlimited,

Control & Program

5 High-end ergonomics buttons

Display: TF display

Protocols: DMX512, RDM

DMX Protocol modes: 2

Control channels: 30/45 Ch

Firmware upgrade via DMX link



Electrical & Connectors

Power supply with electronic auto-ranging

Input voltage range: AC 100-240V, 50/60Hz

Power consumption: 380W

Power in/out: Power Connector in/out

Data in/out: 3-pin & 5-pin XLR



Fixture Specification

560×370×205mm

Weight: 18kg



Work environment

Maximum ambient temperature: 40°C

Maximum surface temperature: 65°C

Minimum operating temperature: 0°C



Approvals

CE compliant



Installation

Horizontal or vertical mounting

Operating position is universal

2x fast-lock clamps for 50mm truss

Safety cable attachment point



Included items

User Manual

Power Cable

Carry handles (minimum load 60kg)

Safety rope device

2x fast-lock clamps for 50mm truss


Applications:

Entertainment: night clubs, live house, Events, DJ, Disco, club, KTV& other entertainment centers …
